Rotex Solenoid Valves represent over 45 years of continuous development in electromechanical valve technology. With a product range spanning 600+ standard variants, Rotex covers a wide range of port sizes, pressure ratings, body materials and coil voltages required by modern process industries.
The range includes direct acting, universal and pilot operated configurations with multiple body and seal material options. Special variants including ATEX-rated explosion-proof and high-pressure types are available depending on the model and application.
Transcon Impex maintains ready stock of commonly required Rotex Solenoid Valve variants in Secunderabad, enabling quick despatch for critical plant requirements.
| Port Size | 1/8" to 3" BSP / NPT |
|---|---|
| Working Pressure | Up to 400 bar, series dependent |
| Temperature Range | –20 °C to +180 °C |
| Orifice Diameter | 0.5 mm to 80 mm |
| Operating Type | Direct Acting / Universal / Pilot Operated |
| Valve Function | 2/2-Way / 3/2-Way / 5/2-Way / 5/3-Way |
| Body Material | Aluminium / Brass / SS304 / SS316 |
| Seal Material | NBR / EPDM / FKM / PTFE, media dependent |
| Coil Voltage | 12V / 24V / 72V / 110V / 230V, others on request |
|---|---|
| Current Type | AC / DC |
| Power Consumption | 3W to 25W, coil dependent |
| Duty Cycle | 100% ED / Continuous Duty |
| Insulation Class | Class F / Class H, model dependent |
| Protection | IP67 standard; hazardous-area options available |
| Response Time | <20 ms for applicable direct acting models |
| Certification | ISO 9001 / TÜV Germany / CE / ATEX for applicable versions |
